RECORDING FRAME RATE – PAL
- HQ mode: 1920×1080/50i, 25P, 1280×720/50P, 25P SP mode: 1440 x 1080/50i
- Native 24P recording
- HQ mode: 100 min. with two 16 GB memory cards
- SP mode: 140 min. with two 16 GB memory car
LENS SPECIFICATIONS
- ½ – inch EX mount
- Zoom ratio: 14x (optical), servo/manual selectable
- Focal length: f = 5.8 to 81.2 mm
(equivalent to 31.4 to 439 mm on 35 mm lens) - Iris: F1.9 to F16 and Close, servo/manual selectable
CAMERA SPECIFICATIONS
- Pickup device: 3-chip ½ – inch type Exmor CMOS
- Effective picture elements: 1920(H) x 1080(V), 16:9 Optical system: F1.6 prism system
- Built-in filters: ND filter OFF: Clear, 1: 1/8ND, 2: 1/64ND Sensitivity: (2000 lx, 89.9% reflectance) F10 (typical)(1920 x 1080/50i mode)
- Minimum illumination: 0.14 lx (typical) (1920 x 1080/50i mode, F1.9, +18 dB gain, with 64-frame accumulation)
- S/N ratio: 54 dB (Y)(typical)
- Horizontal resolution: 1000 TV lines or more (1920 x 1080i mode)
- Shutter speed: 1/33 to 1/2000 sec.
- Shutter angle: 180, 90, 45, 22.5, 11.25 degrees
- Slow Shutter (SLS): 2-, 3-, 4-, 5-, 6-, 7-, 8-, 16-, 32-, and 64-frame accumulation
- Slow & Quick Motion function: (over and under-cranking)
- 720P – selectable from 1 to 60 fps as recording frame rate
- 1080P – selectable from 1 to 30 fps as recording frame rate
SIGNAL INPUTS / OUTPUTS
-
OUT: Composite – BNC, S-Video, Audio – RCA (Ch-1, Ch-2), Timecode – BNC, Component – Mini D, HD / SD-SDI – BNC, 2.0
-
IN: Timecode – BNC, Genlock – BNC, i.Link 4 pin Firewire, USB 2.0
